// OR-SPK-01 · 360° drag to rotate

Rendered from the exact manufacturing model. Printed to order in PETG.

DGX Spark face mount — close-up render of the signature feature
// OR-SPK-01 · engineering drawing as manufactured
FRONT ELEVATION 254 mm 2U · 88 mm SIDE ELEVATION 155 mm deep
OR-SPK-01 · 2U · 10-inch

DGX Spark face mount

A closed-box face mount for the DGX Spark, cloned from our fit-tested switch-mount architecture: the Spark slides in from the rear, seats on a slim bezel lip 1.6 mm behind the front face, and a flex finger clicks behind its rear edge — no straps, no screws into the device. The lattice intake stays visible and breathing in a full-face window; floor, roof, and side walls are hex-vented so front-to-back airflow is untouched. Whole-U sizing: 2U puts the mounting slots exactly on the proven 1U hole rows, so it bolts to any 10-inch rack. One SKU fits the whole GB10 class — Spark, ASUS Ascent GX10, Dell Pro Max, Lenovo PGX all share the 150 × 150 × 50.5 chassis.

Width254 mm · 10-inch standard
Height2U · 88 mm — slots on the standard 1U hole rows
FitsDGX Spark · GX10 · Dell Pro Max · PGX (150 × 150 × 50.5)
RetentionBezel seat + rear flex-finger click
MaterialPETG · 70°C continuous
Hardware4 × M6 included
Lead timeMade to order · 48 hr

// Fits Lab Rax, DeskPi RackMate, and any 10-inch rack

$34made to order · 48 hr
Download the print file (STL)

// Custom sizes, ports, or engraving runs — support@oara.ai
